Introduction
The DS100 embedded bar code reader is an ultra-compact cost-effective laser scanner characterized by very compact dimensions, motor on/off software commands, wide reading width at a short reading distance, lightweight <100 g, built-in RISC decoder, scanning speed of 500scans/sec, dual high speed serial interface, IP65 rugged industrial housing.
Applications
This product series has been developed to satisfy to requirements of the following reference applications: Biomedical analysis machines, Print & Apply systems, ATM (Automatic Teller Machines), Video rental machines
Features
Straight and 90° output window
500scan/sec
2 input + 2 output
RS232 + RS485 serial port
5Vdc
Winhost programming tool
Typical reading range: 50 - 200mm
