ARGOX >> IX4-240 >> 99-IX402-003
IX4-240
Zoom
Category:
BARCODE PRINTER
Brand:
ARGOX
Part No:
99-IX402-003
Barcode:
99-IX402-003
Model:
IX4-240
Print
Type:
MAIN UNIT
OrderNo:
22701479
Ask Quote
Description:
IX4 240 SERIES 99IX402003 203DPI 4INCH WITHOUT LCD DISPLAY DARK GREY 6IPS TCPIP USB RS232 32MB SDRAM 16MB FLASH ROM WITH 2 USB HOST 6IPS

Introduction
Replacement printer to Argox existing popular X1000, X1000VL and X1000VL series printer. With new mechnical design, iX4-240 supports a large 8.26 inch outer diameter label roll and up to 450 meter ribbon capacity.Featuring 6 ips print speed, even print with the highest speed, it can still maintain the perfect print quality.The iX4-240 has built-in Ethernet, Dual USB hosts, USB device, RS-232, and it can be expanded with Wi-Fi, GPIO card/Parallel port.

Specification

 Printing MethodDirect Thermal & Thermal Transfer
  Printing Resolution203 dpi(8 dots/mm)
  Printing SpeedMax. 6 ips
  Printing LengthMax. 100”(2540mm)
  Printing WidthMax. 4.25” (108mm)
  Memory32 MB SDRAM, 16MB Flash ROM (USB storage up to 32GB)
  CPU Type32 bit RISC microprocessor
  SensorsReflective sensor x 1 (Movable) & Transmissive sensor x 1(Movable)
  Operation InterfaceLED Indicator x 3, Botton(Feed) x 3
  Communication InterfaceUSB device, RS-232, Ethernet, USB host x 2
  FontsInternal character sets standard 5 alpha-numeric fonts from 0.049”H ~ 0.23” H (1.25mm ~ 6.0mm) Internal fonts are expandable up to 24x24 4 direction 0 ~ 270 rotation Soft fonts are downloadable Ability to print any Windows True Type font easily Support scalable font
  Wireless SecurityN/A
  1D BarcodesUPC-A, UPC-E, JAN/EAN, CODE39, CODE93, CODE128, GS1-128 (UCC/EAN128), CODABAR (NW-7), ITF, Industrial 2of5, MSI, UPCadd-on code, POSTNET, GS1 DataBar Omnidirectional, GS1 DataBar Truncated, GS1 DataBar Stacked, GS1 DataBar Stacked Omnidirecional, GS1DataBar Limited, GS1 DataBar Expanded, GS1DataBar Expanded Stacked
  2D BarcodesQR Code, PDF417 (includingMicroPDF), DataMatrix (ECC200), GS1 DataMatrix, MaxiCode
  GraphicsPPLA: PCX, BMP, IMG, HEX,GDI PPLB: PCX, BMP, Binary raster, GDI PPLZ: GRF, Hex, GDI
  EmulationPPLA, PPLB, PPLZ
  Software-label EditingWindows Driver (Windows Vista/Win7/Win8/Win10), BarTender® from Seaguall Scientific
  Windows CompatibilityN/A
  Software-utilityPrinter Tool
  Media TypeRoll-feed, die-cut, continuous, fan-fold, black mark, tags, ticket in thermal paper or plain paper
  MediaMax. width:4.48”(114mm). Min. width: 1” (25.4 mm). Thickness: 0.0025”~0.01” (0.0635mm~0.254mm) 8.26”(210mm)OD on a 3”(76mm) ID core. 7”(177.8mm) OD on a 1.5”(38mm) ID core.
  RibbonMax. width:4.4”(112mm). Min. width: 1” (25.4 mm). Length: 450m Wax, Max OD 3.2” (81.3mm). Core size ID 1”(25.4mm). Wax, Wax/Resin, Resin (Ribbon wound ink-side out or ink-side in: auto-detect)
  Drop ResistanceN/A
  Printer DimensionsW 257 mm x H 263 mm x D 432 mm
  Printer Weight13 kgs
  Power SourceInternal Universal Switching Power supply. Input voltage: 100~240V, 50~60Hz
  BatteryN/A
  Operation EnvironmentOperation Temperature: 40°F~104°F (4°C~40°C), 0% ~ 90% non-condensing, Storage Temperature: -4°F~122°F (-20°C~50°C)
  Real Time ClockN/A
  Standard ItemN/A
  Optional ItemsGuillotine-Full Cutter / Partial Cutter, Rotary Cutter, Peeler, WLAN, GPIO, Parallel module, External media stand
  Agency ListingCE, CB, cULus, FCC, ICES, Energy Star, RoHS, BSMI
  Attention*Argox reserves the right to enhance and modify the specification without prior notice. Please check Argox sales representative for most updated specifications.


BROCHURE




Below picture may contain accessories which may not include in the product you purchase, call our sales agent to verify before purchase.
