Product Details

BRAND: AMC >> MODEL: iFACE800EF >> PART NUMBER: iFACE800EF
iFACE800EF

IFACE800EF FACE RECOGNITION EM READER FINGER TIME ATTENDANCE ACCESS RS232/485 TCPIP 1200USERS

  • Category: ACCESS CONTROL SYSTEM
  • Brand: AMC
  • Model: iFACE800EF
  • Part No: iFACE800EF
  • Barcode: iFACE800EF
  • Type: MAIN UNIT
  • Description: IFACE800EF FACE RECOGNITION EM READER FINGER TIME ATTENDANCE ACCESS RS232/485 TCPIP 1200USERS
Order No: TRA00435

Product Overview

Introduction:
iface801 is a streamlined face and RFID identification T&A and access control terminal which has an enlarged capacity of 1, 200 faces, 10,000 cards and 100,000 records. The capacity is larger but the performance and verification are still extremely reliable and fast. It can meet the demands of  companies of different size.
Multi-model communications consisting of RS232/485, TCP/IP, USB host and Wi-Fi/GPRS (optional) allow an extremely easy data management. Optional built-in 2000 mAh battery eliminates the trouble of power failure. It also has many useful functions like DST, T9 input, Photo ID, Automatic Status Switch, Self-Service Query, camera, Scheduled-bell.
It enables enterprise to manage more employees with less cost.

Features:
Capacity: 1, 200 faces, 10,000 cards and 100,000 records
Identification methods include Face, RFID and Password
Elegant ergonomic design
4.3’’ TFT touch screen
Intuitive touch screen GUI
6 user-defined function keys
Optional built-in battery backup provides approx. 4 hours continuous operation
Optional built-in wireless Wi-Fi or GPRS for wireless connection
Built-in interfaces for third party electric lock, door sensor, alarm, exit button
Wiegand output for connections to third party access control panels

Specifications:
Face Capacity 1, 200 (1:N)
ID Card Capacity 10,000
Record Capacity 100,000
Camera High Resolution Infrared Camera
Display 4.3’’ TFT touch screen
2000mAh Backup Battery
Optional: Communication TCP/IP, RS232/485, USB-host,
Optional: Wireless Wi-Fi, GPRS,
Time Attendance Standard Functions
ID Card , Automatic Status Switch, Self-Service Query, Work Code, T9 input, 9 Digit User ID, DST, Photo ID, Schedule Bell
Access Control Interfaces for Third party electric lock, door sensor, exit button Wiegand Signal Output
Optional Functions Mifare card, Wi-Fi, GPRS, External Schedule Bell
Power Supply 12V3A
Verification Speed <=2 sec
Operating Temp. 0 centigrade - 45 centigrade
Operating Humidity 20%-80%
Dimension 193.6*165*111 mm (Length*Width*Thickness)
Net Weight 1.70 kg







Videos Related to This Product

No videos available for this product.


Similar Products

No similar products found.


Accessories Suggested for This Item

Accessories suggested for this item
Item CodeDescription
PS902B PS902B 12VDC FROM AC 220V 50HZ 5A 2A POWER SUPPLY COME WITH METAL BOX AND INTERNAL RELAY
EMLOCK EL600L EMLOCK WITH DUAL COLOUR LED SINGLE WITH BUILD IN SENSOR 12V OR 24V
ELBKZ600 EMLOCK ZLBRACKET ELBKZ600 FOR EMLOCK 600 POUND ZL BRACKET EXCLUDE INSTALLATION AND OTHER ACCESSORIES
ELBKL600 EMLOCK LBRACKET ELBKL600 FOR EM LOCK EXCLUDE INSTALLATION AND OTHER ACCESSORIES
ALUS01EMT TR/AC ACC BREAKGLASS GREEN COLOUR FOR ACCESS CONTROL COME WITH BY PASS KEY EXCLUDE INSTALLATION AND OTHER ACCESSORIES
TR/AC ACC KEYSWITCH ELKS1 2POS 1POLE BY PASS KEY SWITCH FOR ACCESS CONTROL EXCLUDE INSTALLATION AND OTHER ACCESSORIES
TR/AC ACC EXIT PUSH BUTTON PLASTIC EMERGENCY OPENING UP TO MINIMUM 1 MILLION PRESS WITH SCREW EXCLUDE INSTALLATION AND OTHER ACCESSORIES
remote31 REMOTE PUSH BUTTON 1 REMOTE SESOR & 1 RECEIVER WITH DIP SWITCH BLACK COLOUR
TR/AC ACC SENSOR REMOTE CONTROL WITH DIP SWITCH BLACK COLOUR FOR REMOTE PUSH BUTTON EXCLUDE INSTALLATION AND OTHER ACCESSORIES
TR/AC ACC ELEB1 PUSH BUTTON STAINLESS FOR DOOR ACCESS USE EXCLUDE INSTALLATION AND OTHER ACCESSORIES
PL-800Z PL800Z AVR RIGHT POWER 4 SOCKET WITH LCD 800VA FOR BARCODE PRINTER TIME CLOCK AND ACCESS CONTROL AUTOMATIC VOLTAGE REGULATOR STABILIZER AVR
AL-200PZ AL200PZ ELECTRIC BOLT BRACKET IN FRAMELESS GLASS DOOR FOR BIG MAGNETIC PLATEIN DROP BOLT 12VDC 800MAH EXCLUDE INSTALLATION AND OTHER ACCESSORIES
AL-100PF AL100PF ELECTRIC BOLT BRACKET IN FRAMELESS GLASS DOOR FOR SMALL MAGNETIC PLATEIN DROP BOLT EXCLUDE INSTALLATION AND OTHER ACCESSORIES
AL-300 AL300 ELECTRIC DROP BOLT DOOR LOCK POWER ON TO LOCK MAGNETIC INDUCTION WITH LOCK LED DISPLAY 12V DC
