| Specification |
Xenon Ultra 1960g |
Xenon XP 1950g |
| Processor |
1.4GHz dual-core |
800MHz |
Image Sensor
(Pixels) |
1280 x 1080 |
1280 x 800 |
| Aimer Type | Green dot | Red bar |
| Illumination | Warm White Illumination | White Illumination |
Motion Tolerance
Meters/Second | SR: 4 m/s HD: 3.4 m/s | SR: 4 m/s HD: 3.4 m/s |
| Scan Angle | SR: Horizontal: 42°; Vertical: 36°
HD: Horizontal: 42°; Vertical: 36°
LI: Horizontal: 30°; Vertical: 25° | SR: Horizontal: 42°; Vertical: 27°
HD: Horizontal: 42°; Vertical: 27°
UD: Horizontal: 40°; Vertical: 26° |
| Roll, Pitch, Skew | ±360°, ±65°, ±65° | ±360°, ±45°, ±65° |
| Durability | Environmental sealing: IP52
Drop: 50 1.8 m drops to concrete
Tumble: 2,000 @ 0.5m | Environmental sealing: IP52
Drop: 50 1.8 m drops to concrete
Tumble: 2,000 @ 0.5m |
Host System
Interfaces | USB,
Keyboard Wedge,
RS-232 | USB,
Keyboard Wedge,
RS-232 and
RS485 |
| DoF | SR: 0-654mm
HD: 0-502mm
LI: 26-199mm | SR: 0-490mm
HD: 0-368mm
UD: 0-190mm |
| 13mil UPC | SR: 0-495mm
HD: 0-392mm
LI: 11-179mm | SR: 0-438mm
HD: 0-331mm
UD: 0-160mm |
| 20mil QR | SR: 0-495mm
HD: 0-392mm
LI: 11-179mm | SR: 0-438mm
HD: 0-331mm
UD: 0-160mm |
