BRAND: ZEBRA >> MODEL: ZT421 >> PART NUMBER: ZT42163-T4P0000Z

ZT421
Category:
BARCODE PRINTER
Brand:
ZEBRA
Model:
ZT421
Part No:
ZT42163-T4P0000Z
Barcode:
ZT42163-T4P0000Z
Type:
MAIN UNIT
Description:
ZT42163T4P0000Z,ZT421,6INCH,300DPI,RS232,USB,10/100 ETHERNET,BT 4.1/MFI,USB HOST,DT/TT, COLOUR LCD, RTC,256MBRAM,512MBFLASH,EZPL PRINT WIDTH:6INCH,SPEED 10IPS, PEEL WITH FULL REWIND, UK CORD
OrderNo:
22702051


Introduction
ZT421 is the facelift model from existing ZT420 printer with enhance in term of user interface and user experience when using this printer. The first change is upgraded it Monochrome LCD monitor to interactive touch screen monitor. This 6 inch full colour touch screen display allow users have better understanding on the printer operation and setting changes much easier compared with previous ZT420 model. Indirectly, this helps the setup technician can shorten their installation time and have better alert message to the user just in case any problem happen on the printer. ZT421 come with standard 256MB ram and 512MB flash and built in real time clock chip, this ZT421 now enhanced with QRcode function to allow binding between mobile device make simple between printer and mobile computer. It standard connectivity include Serial, USB, Ethernet, BT 2.1 and you make add on communication include Parallel, 802.11ac/BT 4.1 (dual band), Ethernet, IPV6. Select the printing option from 203 and 300  dpi with tool-less printhead changing. Same as previous ZT420, ZT421 still maintain it maximum ribbon length of 450meter and maximum label media outer diameter at 8 inch.

Feature

Color LCD for a more modern, intuitive user experience
Color coded alerts
Optional dual-band wireless card supports 802.11ac and Bluetooth 4.1,
Bifold door for space efficiency
Energy Star power consumption
Built-in help feature with QR Code
Standard Connectivity Serial, USB, Ethernet, BT 2.1


BROCHURE




Below picture may contain accessories which may not include in the product you purchase, call our sales agent to verify before purchase.


Video related to this product

Zebra ZT400 Series: How-to Replace the Printhead

Zebra ZT400: How-to Clean the Printhead & Platen

Zebra ZT400 Series: How-to Install the Cutter

Zebra ZT400 Series: How-to Install the Peel Option

Zebra ZT400 Series: How-to Replace the Platen Roller

Zebra ZT400 Series: How-to Load Ribbon and Media

Zebra ZT400 Series: How-to Install Liner Take-up

Zebra ZT400 Series: Auto Calibration

Zebra ZT400 Series: How-to Manually Calibrate

Zebra ZT400 Series: How-to Clean the Media Sensors & Exterior

Zebra ZT400 Series: How-to Install RFID Option

Zebra ZT400 Series: How-to Install a USB



Item related to this product
